A roof with a vision – green solutions for investments

Modern green roofs as a key element of sustainable construction

Green roofs in modern construction are not a passing trend, but a real market need driven by climate, urbanisation and regulatory challenges. They are a key element of sustainable development strategies, not only distinguishing investments on the market, but also having a real impact on their value and functionality. It is a space where ecology meets long-term safety and technical durability.

Green roofs and sustainable construction

Dynamically developing cities need solutions that will support adaptation to climate change and improve the quality of life of their residents. Green roofs effectively reduce the formation of urban heat islands, improve air quality, increase rainwater retention and enable an increase in biologically active areas in densely built-up areas. They are an indispensable element of investments that want to meet environmental requirements and comply with the latest standards of ecological construction.

Key layers of the system

The durability of every green roof is based on a comprehensive, well-thought-out layered structure. Efficiency and trouble-free operation depend on the correct selection and arrangement of individual layers. Each of them plays a key role, affecting the durability of the entire investment.

Green roof waterproofing – the basis for structural safety

The most important element is, of course, the waterproofing layer, which acts as a barrier against water penetration, root penetration and the effects of chemicals from the soil. Its tightness and durability determine the safety of the entire structure. NEXLER bituminous felts (e.g. Green Roof PYE PV250 S50) not only fully meet these requirements, but thanks to double SBS modification, they also combine high damage resistance with flexibility, even in extreme temperatures. This combination guarantees durability and reliable protection for years to come, both in green roofs and on intensively used surfaces.
The system is further complemented by Connect NexGreen, which is used for the fast, durable, and watertight execution of flashings and sealing details, such as service penetrations. The product retains all the benefits of the standard Connect solution while also featuring resistance to root penetration, allowing for its safe application in green roof systems.

Drainage layer and water retention on a green roof

Another important aspect is water management. The drainage layer is responsible for draining excess rainwater, protecting the structure from overload or the effects of frost (e.g. NexGreen Duo 10/400). In intensive roofs, where water demand is higher, water retention in special accumulation spaces becomes particularly important, as water is stored to support plant growth and increase the roof’s resistance to periods of drought.

Filter and separation layer – protection against system silting

Directly above the drainage layer, there is usually a filtration layer whose task is to retain solid particles contained in the substrate (e.g. NexGreen Geo 110). Thanks to this, the drainage system does not become silted up and the water drainage remains unobstructed even after many years of use. Calendered geotextiles (e.g. NexGreen Geo Safe 350) can also act as a separation layer, protecting the waterproofing against mechanical damage and separating materials with different properties.

Innovative protective and drainage membranes

In some solutions, the drainage and filtration layers can be combined into a single layer, creating a protective and drainage membrane integrated with geotextile (e.g. NexGreen Duo BB 20/200 P). This simplifies the design, reduces the number of materials used and, as a result, lowers costs and increases the efficiency of the roofing system.

What is geotextile calendering?

It is a process of mechanical compaction and smoothing of fibres under the influence of high temperature and roller pressure. This makes the material more compact, resistant to abrasion and mechanical damage, and its surface smooth and less absorbent. In practice, calendered geotextiles better protect roof layers (e.g. waterproofing), reduce root penetration and improve separation between materials with different properties.

Stabilising geogrid – green roof on slopes and heavily used surfaces

On roofs with varied structures or slopes, a reinforcing and stabilising layer, known as a geogrid (e.g. NexGreen Road 440/75/13), is particularly important. Its role is to keep the layers and substrate in the correct position and to distribute loads evenly. Thanks to this, it is possible to construct green roofs even on slopes and in areas exposed to heavy foot traffic.

NEXLER system warranty – reliability and durability for years to come

Each of these layers has a specific responsibility – and their mutual synergy creates a complete, effective roofing system. That is why NEXLER offers up to a 35-year system warranty – for roofs constructed in accordance with our design and material recommendations. This is not only proof of confidence in the technology, but also real security for the investor.

Click to explore our green roof systems.

Professional support at every stage of implementation

Over more than three decades of operation, we have learned that the real value of a green roof only becomes apparent when the design and construction are based on proven, compatible materials and a well-thought-out system. By working with NEXLER, investors not only gain access to the latest technologies and certified solutions, but also receive technical support at every stage of the investment. Our consulting services include professional training and ongoing cooperation directly on the construction site, as well as continuous support via a technical helpline.
